JX Servo C70 SPECIFICATIONS

Brand Name: NoEnName_Null

Origin: Mainland China

Material: Metal

Recommend Age: 14+y

RC Parts & Accs: Servos

Size: 40X20X43.3mm

For Vehicle Type: Airplanes

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories: Gear

Remote Control Peripherals/Devices: Servos

Tool Supplies: Assembled class

Technical parameters: Value 5

Model Number: C70

Four-wheel Drive Attributes: Assemblage

Wheelbase: Screws

JX Servo Technology have established a reputation for reliability and value. JX Servo produce servos for all applications from RC Modelling. UAV. Robotics to industrial applications. JX Servo offer an affordable solutions for all kinds of servo applications and are backed up with years of R&D and production development to ensure reliable quality servos are always delivered quickly.

FEATURE:
— 12V High voltage
— High performance digital coreless standard servo
— High-precision Taiwan-made steel gears with hard anodizing
— Full CNC aluminium Shell structure
— Dual ball bearings

SPECIFICATIONS:

Dead band: 2μs
Working frequence: 1520μs / 330hz
Motor: coreless motor
Operating Speed (11.1V): 0.10sec/60°
Operating Speed (12.0V): 0.08sec/60°

Stall Torque (11.1V): 61kg.cm

Stall Torque (12.0V): 72kg.cm
Dimensions: 40X20X43.3mm

Weight:  87 g
Connector Wire Length: JR  265 mm
Bearing: 2BB
