Description
The Flywoo GOKU V3 HD Stack combines high-performance components in a compact 16x16mm design! This stack features an F4 flight controller and a 35A 2-6S 4-in-1 BLHeli_S ESC. Equipped with a built-in LED, the drone will have improved visibility during flight. Designed for performance, the Flywoo GOKU V3 HD Stack is a perfect choice for FPV enthusiasts seeking efficiency and durability.
Make sure to check out our other Stacks and the rest of our Flywoo selection.
Features
- Direct Plug-in for DJI O3/O4 Air Unit
- FC/ESC Pin Header Interface
- Built-in TCXO ELRS Receiver
- Universal USB-C Interface
- 16×16 Mounting Holes
- Built-in Barometer
- 16MB Black Box
Specifications
ESC
- Supports: PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600
- Size: 27×33mm board, 16mm mounting holes (M3)
- Continuous Current: 35A
- ESC MCU: BB21F16G
- Input: 2-4S LiPo
- Power LED: No
- Weight: 3.6g
FLIGHT CONTROLLER
- Input Voltage: 7.4V – 24V / 2 – 6S LiPo
- Hole Position: M2 16x16mm
- Size: 25mm x 23mm x 8mm
- IMU (Gyro): ICM42688P
- MCU: STM32F405 BGA
- Gyro: ICM-42688P (SPI)
- BEC: 5V 2A / 3.3V 0.5A
- USB Port Type: Type-C
- UARTs: 1, 2, 3, 4, 5, 6
- Barometer: DP310
- Black Box: 16MB
- Weight: 3g
- OSD: No
Includes
- 1x Flywoo GOKU QUAD V3 35A 2-6S 4-in-1 BLHeli_S ESC w/ LED – 16×16
- 1x Flywoo GOKU V3 F4 Flight Controller w/ ELRS 2.4GHz – 16×16
- 1x DJI O3 Connection Cable
- 8x Shock-Absorbing Balls
- 1x XT30U Power Cable
- 1x Hardware Kit
- 1x Capacitor
