Description
Sunnysky Eolo 50A ESC supports 4-6s power supply. It is great for multi-rotor drones.
Specifications:
| ESC Model | EOLO 4-6S 50A-PRO |
|---|---|
| Maximum allowed voltage | 25.2V |
| Maximum allowed current | 50A |
| Maximum allowed peak current(3s) | 70A |
| OneShot125 Maximum compatible signal frequency | 500 Hz |
| Maximum compatible normal signal frequency | 500 Hz |
| PWM Default output frequency | 16 KHz |
| Power cord | 400mm／16AWG |
| Motor wire | 100mm／16AWG |
| ESC weight(wire included) | about 84.5a g |
| Battery support | 3S – 6S LiPo |
| Working temperature | -20 to 40°C |
| Motor recommended use( including but not limited) | 3506、3508、3510、3708、3712、3515、3520、4004、4006、4008、4010、4012、4014、 4110、4112、4115、4510、4806、4808、4810、5008、5010、5208、5210、5212、5310、 5312、6008、6010、6210、7204、7205、7206、7208、8108、8110、8114 |
Package Included :
Sunnysky Eolo 50A Pro 4-6S Brushless ESC x 1
