Description

SPECIFICATIONS

Wheelbase: Screws

Use: Vehicles & Remote Control Toys

Upgrade Parts/Accessories:Lithium Battery

Tool Supplies: Assembled class

Technical parameters: Value 2

Remote Control Peripherals/Devices: drone electric motor

Recommend Age: 12+y

RC Parts & Accs: Motors

Quantity: 1 pcs

Origin: Mainland China

Model Number: Xing-E 2207 Pro

Material: Metal

Four-wheel Drive Attributes: Motors

For Vehicle Type: Airplanes

Brand Name: NoEnName_Null

PRODUCT DESCRIPTION

XING-E
series are very strong and powerful FPV motors for FPV racing. great
value choice with well known XING performance.focuses on quality. the
XING-E series affordable motors that are strong and durable.

This
2207 sized motor features a High-strength 4mm steel hollow shaft.
Single strand windings for performance. M3 shaft screw. and larger
9x4x4mm NSK bearings.

Features

-High-strength 4mm Steel shaft

-N52H High-temperature magnets. NSK bearings

-16x16mm hole pattern

-Single strand copper winding

-Hex bolt shaft set screw

Specifications

-Configuration:12N14P

-Stator Diameter:22mm

-Magnets: N52SH Curved

-Bearing Size: 9x4x4

-Shaft Diameter: 4mm / Steel

-Base Mounting Pattern: 16x16mm M3 Thread

-Motor Dimension: 28.5×19.7mm

-Weight: 33.8g (150mm wires)

-Idle Current @12.6v (Io):1.2 A

-Cells (LiPo): 2-6S

-Max Burst Current <10s: 35.22A

-Max  Power (W) 60s: 845W

-Internal Resistance (Rm):81.5mΩ

-Motor Wire Length:150mm / 20AWG
