Description
Spare replacement Flight Controller for the Happymodel Mobula 6, and an all around incredible little TRUE AIO for any 1S brushless build!
Check out all our Whoop FCs, our Mobula 6 parts selection, and all Happymodel products!
Specifications
Flight Controller
- (Frsky SPI RX version) CRAZYBEE F4 Lite Frsky version Firmware target: CrazybeeF4FR
- (Flysky SPI RX version) CRAZYBEE F4 Lite Flysky version Firmware target: CrazybeeF4FS
- MCU:STM32F411CEU6 (100MHZ, 512K FLASH)
- Sensor: MPU-6000(SPI connection)
- Board size: 28.5 * 28.5MM
- Approximate Weight: 4.5g
- Power supply: 1S battery input (DC 2.9V-4.35V)
- Built-in 5A(each) Blheli_S 4in1 ESC Dshot600 ready
- Built-in Betaflight OSD(SPI Control)
- Built-in 5.8G VTX
- Built-in SPI Frsky/Flysky receiver
- Built-in 5V 1A BEC
- Built-in voltage detection
Onboard 4in1 ESC
- MCU upgraded to EFM8BB21
- Power supply: 1S LiPo/LiPo HV
- Current: 5A continuous peak 6A (3 seconds)
- Support BLHeliSuite programmable
- Factory firmware: O_H_5_REV16_7.HEX
- Default protocol: DSHOT600
Onboard FrSky SPI D8 Receiver Version
- SPI BUS receiver Frsky D8 compatible
- Compatible Non EU transmitter D8 model
- Channels: 8ch
- Failsafe support
- No ground interference ( Transmitter and receiver 1 m from the ground): 100m~200m
Onboard FlySky SPI Receiver Version
- SPI BUS receiver
- Protocol: AFHDS and AFHDS-2A Switchable
- Channels: 8ch(AFHDS) or 14ch(AFHDS-2A)
- Failsafe support
- No ground interference ( Transmitter and receiver 1 m from the ground): 100~200m
Onboard 5.8GHz VTX
- Output power: 25mw
- Frequency: 40CH
- Input voltage: 3.3V 5.5V
- Current consumption: 300mA(type)
- Frequency: 5.8GHz 5bands 40 channels
- With Race band
- Smartaudio ready
Includes
- 1x HappyModel Crazybee F4 Lite 1S Whoop Flight Controller – Choose Your RX
