Description
The Foxeer Micro Cat 4 Starlight camera features a Sony 1/3″ CMOS sensor with 1200TVL resolution and a low-light 2.1mm lens for clear, detailed video. It supports 4:3 or 16:9 aspect ratios, PAL/NTSC systems, and includes wide dynamic range, 3D noise reduction, and on-screen flight OSD.
Check out the rest of our ever-growing selection of Micro FPV Cameras and our entire Foxeer Collection!
Features
- Sony 1/3″ CMOS sensor for high-resolution video
- 1200TVL output with low-light 2.1mm lens
- Switchable 4:3 and 16:9 aspect ratios
- Wide dynamic range and 3D noise reduction
- On-screen display for voltage, camera title, and time
Specifications
- Sensor Type: Sony 1/3″ CMOS
- Aspect Ratio: 4:3 (Default) / 16:9 Switchable
- TV System: PAL (Default) / NTSC Switchable
- Resolution: 1200TVL
- Lens: M12 2.1mm Low Light Lens
- Field of View (4:3): H: 95° / V: 72° / D: 120°
- Field of View (16:9): H: 95° / V: 53° / D: 110°
- Shutter Speed:
- PAL: 1/25 ~ 1/10000 sec
- NTSC: 1/30 ~ 1/10000 sec
- Video Output: CVBS Analog
- Minimum Illumination: 0.00001 Lux
- White Balance: Auto
- DNR: 3DNR
- WDR: 100dB
- Day/Night Mode: EXT / Auto / Color / B&W
- Flight OSD: Voltage / Camera Title / Time
- Input Voltage: 5V–20V
- Power Consumption: 95mA ±15% @ DC 12V
- Operating Temperature: -10°C to 50°C (RH 90% Max)
- Operating Humidity: 20%–80%
- Storage Temperature: -20°C to 70°C
- Dimensions: 19 × 19mm
- Weight: 11.8g (excluding cable)
